Eaton Power Xpert 9395 with Samsung Lithium-Ion Battery CabinetHave high-power needs and not a lot of space?

We’ve can develop a system for you that’s sure to help.

The EATON Power Xpert 9395 UPS (formerly the Powerware 9395) provides industry-leading efficiency and scalable battery runtimes in a small footprint, especially when paired with the new Samsung SDI lithium-ion battery for UPS.

This three-phase solution, with models offering power ratings from 225 kVA to 1200 kVA (including high-performance models), is perfect for large data centers, healthcare applications, multi-tenant data centers, light industry, and other critical systems. Lower your total total cost of ownership by leveraging longer-lasting and reduced-maintenance lithium-ion batteries and the ground-breaking Energy Saver System from EATON. Monitor and manage your 9395 UPS with the 10-inch color LCD touchscreen display.


Features & Benefits Of EATON 9395 Uninterruptible Power Supply (UPS System)

  • Innovative Energy Saver System operates at 99 percent efficiency without sacrificing reliability;
  • Double-conversion efficiency (up to 97% with the new high performance model), superior battery management, and exclusive Easy Capacity Test deliver higher reliability and stronger power performance;
  • Eaton Hot Sync paralleling, inherent redundancy, and a scalable architecture adapt to your increasing power requirements;
  • Large 10-inch color touchscreen provides superior control and connectivity;
  • Works with the Intelligent Power Software Suite, which offers free monitoring, management, and shutdown software ideal for protecting physical and virtual machinery;
  • Lowest total cost of ownership through, 33 percent less heat, and up to 20 percent more power in the same footprint with the high performance model;
  • Money savings and protecting the environment through energy efficient operation (ENERGY STAR® qualified UPS) and by not using inefficient and often-replaced lead-acid batteries.

Benefits of Lithium-Ion

Lithium-ion chemistry has become safer, more reliable and more affordable as research has improved the energy storage technology. Lithium-ion has superior characteristics (when compared to valve-regulated lead acid, or VRLA, batteries) in UPS systems, resulting in longer life, higher energy density, flexible installation options, longer life, more charging cycles and a lower total cost of ownership.

Save Money

  • 10-year performance warranty
  • 15-year design life (replace fewer batteries over time)
  • Reduces total cost of ownership

Save Space

  • 8x Cycle
  • 40% smaller than lead acid
  • 60% lighter than lead acid
  • Megawatts of power in a small footprint

Reduce Risk

  • 24/7 Battery Management System (BMS) monitoring
  • Cell protection (temperature, current, over/under voltage) cell balancing, state of charge, health and alarms/reports.
  • If abnormal conditions exist, the BMS will protect the system from damage by disconnecting the affected battery.
  • BMS also optimizes voltages in each battery module to maximize performance and increase service life.

About the Samsung SDI Lithium-Ion Cabinet

Samsung SDI’s lithium-ion battery for UPS is capable of supplying a large current (450A) and is compatible with major global UPS companies.

Less Space/Weight

  • Less space for battery room
  • No structure reinforcement required

Longer Life

  • Battery replacement deferral
  • Enhanced reliability

Fast Charge/Discharge Rate

  • No oversizing required
  • Shorter charging time
Product Snapshot
Power Rating 225-1100 kVA, High performance model: 200-1200 kW/kVA
Voltage 480V standard; 400V optional and 600/575V optional
Frequency 50/60 Hz
Configuration Tower
Product Series Powerware

Models

Part NumberPower RatingVoltageESS EfficiencyDouble Conversion Efficiency
9395 UPS Models (all models are TAA Compliant)
Power Xpert 9395225 to 1100 kVA480V and 400V99%94%
Power Xpert 9395 high performance 480V200 to 1200 kVA/kW480V99%up to 97%
Power Xpert 9395 high performance 400/415V200 to 1100 kVA/kW400/415V99%up to 96%
Power Xpert 9395 high performance 600/575V200 to 1100 kVA/kW600/575V99%up to 96%

Technical Specs

TECHNICAL SPECIFICATIONS FOR POWER XPERT 9395 UPS

UPS RATING (0.91 POWER FACTOR)
kVA225 / 250 / 450 / 550 / 750 / 825 / 1100
kW205 / 228 / 410 / 450 / 683 / 751 / 1001
GENERAL CHARACTERISTICS
Efficiency>94% (99% with Energy Saver System)
Parallel capability4 distributed, 32 with SBM
Maximum modules per sizeUp to 3 modules, 550 kVA, up to 4 modules, 825/1100 kVA
Audible noise<76 dBA @ 1 meter
Altitude (max)2000m at 40°C (104°F)
N+1 Redundancy CapableYes
Field upgradeableYes
System bypass moduleIncluded
INPUT CHARACTERISTICS
Voltage480V standard; and 400V available
Voltage range-0.666666667
Frequency range45-65 Hz
Power factor0.99(minimum)
Input current distortion<3.5% (no input filter required)
Soft start capabilityYes
Internal backfeed protectionYes
OUTPUT CHARACTERISTICS
Voltage480V standard; and 400V available
Regulation± 1%
InverterPWM with IGBT switching
Voltage THD<2% (100% linear load); <5% (non-linear load)
Load power factor rangeUp to a .9 power factor leading without derating
BATTERY
Battery typesLithium-Ion, VRLA, AGM, Wet Cell
Battery voltage480 V
Temperature compensationOptional
Charging methodABM technology or Float, Selectable
DIMENSIONS & WEIGHTS
225 kVA, 250 kVA, 275 kVA52.8”w x 34.4”d x 73.9”h, 1900 lb
225, 250, 275 kVA redundant73.6”w x 34.4”d x 73.9”h, 3150 lb
450, 500, 550 kVA73.6”w x 34.4”d x 73.9”h, 3274 lb
450, 500, 550 kVA redundant102.9”w x 34.4”d x 73.9”h, 4654 lb
Field upgrade module, 225, 250, or 275 kVA29.3”w x 34.4”d x 73.9”h, 1380 lb
650, 750, 825 kVA140.3″w x 34.4″d x 73.9″h, 5500 lb
650, 750, 825 kVA +1 redundant169.6″w x 34.4″d x 73.9″h, 6930 lb
1000, 1100 kVA169.6″w x 34.4″d x 73.9″h, 7050 lb
GENERAL CHARACTERISTICS
Control panel (LCD)10-inch Color Touchscreen with LED panel
Battery startupStandard
Frequency conversionStandard
Multi-languageStandard
Buildings alarm inputs5 (galvanic isolated)
CERTIFICATIONS
SafetyUL1778, cUL
EMCIEC 62040-2, EN50091 Class A (restricted access)

1. Due to continuous product improvements, program specifications are subject to change without notice.


Samsung SDI Lithium-Ion Battery Cabinet

ItemModule  Rack
ModelU4-M020U6-M020UC-M010U4-R070U6-R035
Cell Capacity (Ah)6767356767
Energy (kWh)2217035
Operating Voltage24~33.623~33.624~33.6408~572408~572
Dimensions (mm) (WxDxH)216x414x163216x414x163216x414x163600x920x1,878600x920x1,878
Weight (kg)171717745550

Industries & Applications

A powerful solution for medium-sized banking centers, clinics & hospitals, financial institutions, and other users who require a complete industrial UPS system or commercial UPS system, the EATON 9155 UPS is also rugged & robust enough for demanding marine applications. Perfect for uses including but not limited to:

  • Medium-sized data centers, IT systems, or telecom closets
  • Network switching & processing equipment
  • PLC controls
  • High-quality power backup system for AS-400 systems

Other Uninterruptible Power Supply Models

Part Number Power Rating (VA/Watts) ESS Efficiency Double Conversion Efficiency
Power Xpert 9395 225 to 1100 kVA 99% 94%
Power Xpert 9395 High Performance 675 to 1100 kW/kVA 99% up to 97%
